Chetan Steel, a reputed manufacturer and supplier in Delhi, India, offers high-quality IS 2002 Gr 1, Gr 2, and Gr 3 Boiler Sheets and Plates designed specifically for boiler and pressure applications. Manufactured with strict quality control and adherence to Indian standards, these plates are known for their reliability, uniformity, and excellent performance under high temperature and pressure conditions. Chetan Steel focuses on delivering boiler-quality steel that ensures safety, durability, and long service life, making these sheets and plates a trusted choice for power plants, refineries, and heavy engineering industries.
IS 2002 boiler plates are carbon-manganese steels with controlled composition suitable for pressure service. Typical chemical composition includes carbon up to 0.20% (Gr 1), up to 0.25% (Gr 2), and up to 0.30% (Gr 3), manganese ranging from 0.60–1.00%, silicon up to 0.35%, with phosphorus and sulfur limited to a maximum of 0.05% each. Mechanically, Gr 1 offers tensile strength of 410–540 MPa, Gr 2 ranges from 440–570 MPa, and Gr 3 from 490–620 MPa, providing increasing strength levels for demanding boiler applications.
| Width | 1000mm-4500mm |
|---|---|
| Thickness | 5mm-150mm |
| Length | 3000mm-18000mm |
| Impact tested | -52° C |
| Material | Pressure Vessel Steel / Boiler Quality |
| Process of Manufacturing | Hot-Rolled (HR) |
| Grade | C | Si | P | S |
| IS 2002 Gr 1 | 0.18 | 0.10 – 0.35 max | 0.40 max | 0.040 max |
| IS 2002 Gr 2 | 0.20 | 0.10 – 0.35 max | 0.50 max | 0.050 max |
| IS 2002 Gr 3 | 0.22 | 0.10 – 0.35 max | 0.50 max | 0.050 max |
| A517 / SA517 Grade B | Tensile Strength (MPa) | Yield Strength (Min MPa) | Elongation min (%) |
| IS 2002 Gr 1 | 37 – 45 | 55 | 26-30% |
| IS 2002 Gr 2 | 42 – 50 | 50 | 25-29 % |
| IS 2002 Gr 3 | 52 – 62 | 50 | 20-24 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Chetan Steel is one of the most prominent manufacturers and suppliers of superior quality IS 2002 Gr1/Gr2/Gr3 Boiler Sheet and Plate in Delhi, India. As experts in steel solutions, we supply a complete spectrum of products like Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our product range comprises Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Known for our reliable delivery and first-rate customer service, we are committed to supplying high-quality steel materials that guarantee durability and excellent performance in numerous industrial applications.Â
IS 2002 Gr 1, Gr 2, and Gr 3 Boiler Sheets and Plates are widely used in the manufacture of boilers, pressure vessels, steam drums, and heat exchangers. These grades are suitable for applications involving elevated temperatures and moderate pressure conditions. They are extensively used in power generation plants, petrochemical industries, fertilizer plants, and oil refineries. Their excellent weldability, formability, and resistance to thermal stress make them ideal for fabrication of pressure equipment. The availability of multiple grades allows engineers to select the right material based on strength and operating conditions.
