Chetan Steel is a prominent producer and seller of superior quality S355JR+N plates and sheets in Delhi, India. With utmost dedication to precision engineering and high-quality material standards, we are delivering long-lasting and high-strength steel solutions to multiple industries like construction, engineering, and manufacturing. Our plates of S355JR+N are of excellent welding properties, impact resistance, and mechanical properties to make them suitable for structural application. At Chetan Steel, we guarantee optimum quality, lowest price, and timely delivery in order to address the variegated needs of our customers locally as well as globally.
S355JR+N plates and sheets are high-strength structural steel with low carbon content, good weldability, and impact resistance. They have a chemical composition of Carbon (≤ 0.24%), Manganese (≤ 1.60%), Silicon (≤ 0.55%), Phosphorus (≤ 0.035%), and Sulfur (≤ 0.035%), which provides better strength and durability.The mechanical properties include a minimum yield strength of 355 MPa, tensile strength of 470-630 MPa, and elongation of 22%. With a Charpy V-notch impact of 27J at 20°C, S355JR+N steel is ideally suited for structural and engineering applications requiring greater toughness and reliability.
Item : S355JR+N – Offshore & Structural Steel Plate
Thickness : 5mm-150mm
Width : 1000mm-4500mm
Length : 3000mm-18000mm or as custom’s request
Material : En 10025-2 Steel Plate, S355JR+N Steel Plate
Technique : hot rolled
Standard : EN 10025-2:2004
| Grade | C | Mn | Si | P | S | N | Cu | CEV |
| S355JR+N | 0.24 max. | 1.6 max. | 0.55 max. | 0.04 max. | 0.04 max. | 0.012 max. | 0.55 max. | 0.47 max. |
| Grade | Thickness (mm) | Min Yield (Mpa) | Tensile (Mpa) | Elongation (%) | Min Impact Energy | |
| S355JR+N | 8mm-100mm | 315-355 Mpa | 450-630 Mpa | 18-20% | 20 | 27J |
| 101mm-200mm | 285-295 Mpa | 450-600 Mpa | 18% | 20 | 27J | |
| 201mm-400mm | 275 Mpa | – | 17% | 20 | 27J | |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
S355JR+N plates and sheets are used extensively in engineering and structural applications because of their excellent weldability, high strength, and impact resistance. They are used in construction, such as bridges, buildings, and structural frames. They are used in the automotive industry and transportation sector for the production of chassis, trailers, and heavy-duty trucks. In manufacturing, they are well suited for cranes, machine parts, and pressure vessels. Ship construction, offshore engineering, and energy industries also use S355JR+N steel due to its longevity in extreme environments. Their high reliability and adaptability make them critical for projects demanding exceptional mechanical properties and performance withstanding prolonged high-stress levels.
