Chetan Steel is a reliable manufacturer and a supplier of high quality 15MO3 pipes in Delhi, the India. Our 15MO3 pipes are known for extraordinary heat resistance and durability, and are widely used in boilers, power plants and industrial pipe systems. They are built to meet international standards, and provide excellent mechanical strength and corrosion resistance to high temperature applications. In Chetan Steel, we prioritize accurately, reliability and customer satisfaction, providing top-class steel solutions for different industries, including petrochemical, chemical and oil and gas areas.
15Mo3 is a low-alloy steel grade primarily composed of carbon, manganese, silicon, and molybdenum. The addition of molybdenum enhances strength, creep resistance, and performance at high temperatures. This material offers good tensile strength, excellent weldability, and reliable impact resistance. Its mechanical properties remain stable under pressure and thermal stress, making it suitable for long-term service. The steel also exhibits good resistance to hydrogen-induced cracking, ensuring safety and durability in critical operating conditions.
| Welded Pipe Size | 5.0 mm – 1219.2 mm |
|---|---|
| Grade 15Mo3 DIN 2609 EFW Pipe size | 5.0 mm – 1219.2 mm |
| CS Tube Swg & Bwg | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg. |
| Standard | AISI, DIN, EN, GB, IS, JIS, ASTM, ASME Pipe |
| Mild Steel Seamless Pipe Size | 4 to 219mm W. T.: 0.5 to 20mm |
| Carbon Steel DIN 2609 Grade 15Mo3 Seamless Tube Size | 3.35 mm OD To 101.6 mm OD |
| DIN 2609 Gr 15Mo3 Pipe Schedule | SCH5, SCH10, SCH10S, SCH20, SCH30, SCH40, SCH40S, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS |
| CS Welded Tube Size | 6.35 mm OD To 152 mm OD |
| DIN 2609 Gr. 15Mo3 Tube wall thickness | 0.020″ –0.220″, (special wall thicknesses available) |
| DIN 2609 Gr St52 Carbon Steel Swg & Bwg | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg. |
| High Temperature Carbon Steel DIN 2609 Gr 15Mo3 Form | Round, Hydraulic, ‘U’ bent or Hollow,LSAW, Boiler, Straight Pipe, Clad Pipe, Rectangular, Square Pipe Etc |
| DIN Gr. 2609 15Mo3 Steel Length | Single Random, Double Random, Standard & Cut length Pipe & Tube |
| Mild Steel Marking | All Tubes are marked as follows: Standard, Grade, OD, Thickness, Length, Heat No. (Or according to the customer’s request.) |
| Low Temperature Carbon Steel DIN 2609 Grade 15Mo3 Application | Oil Pipe & Tube, Gas Pipe & Tube, Fluid Pipe & Tube, Boiler Pipe & Tube, Heat exchanger Tube |
| Type | Welded, Seamless, ERW, EFW, Fabricated Pipe, ‘U’ bent or Hollow, Hydraulic, LSAW, Boiler, Straight Tube, Tube Coil, Round, Rectangular, Square Tube etc |
| DIN Gr. 15Mo3 Finish | Polished, AP (Annealed & Pickled), BA (Bright & Annealed), MF |
| Grade 15Mo3 DIN 2609 Value Added Service | Draw & Expansion as per required Size & Length, Polish (Electro & Commercial) Annealed & Pickled Bending, Machining Etc. |
| 2609 Gr. 15Mo3 End | Plain End, Beveled End, Treaded Pipe & Tube |
| Carbon | Silicon | Manganese | Phosphorous | Sulphur | Molybdenum | Nickel | Chromium | Copper | Others |
|---|---|---|---|---|---|---|---|---|---|
| 0.12 – 0.20 | 0.10 – 0.35 | 0.40 – 0.80 | 0.035 | 0.035 | 0.25 – 0.35 | – | – | – | – |
| Yield Strength | Tensile Strength | Elongation A5 min | |||
|---|---|---|---|---|---|
| MPa min | ksi min | MPa min | MPa min | ksi min | Percentage |
| 450 | 600 | – | 22 | ||
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Chetan Steel is a trusted manufacturer and supplier of 15Mo3 pipes in Delhi, delivering high-quality products that meet international standards. Known for their strength, durability, and excellent performance at elevated temperatures, 15Mo3 pipes are widely used in pressure and heat-intensive applications. At Chetan Steel, these pipes are manufactured using carefully selected raw materials and advanced production techniques to ensure consistent quality and reliability. With a strong focus on customer satisfaction, timely delivery, and technical support, Chetan Steel provides 15Mo3 pipes that perform efficiently in demanding industrial environments.
| Cold Drawn | Outside Diameter, mm | Tolerance | – |
|---|---|---|---|
| outer diameter ≤ 114 | ± 10% or ± 0.2mm | – | |
| Hot rolled | Outside Diameter, mm | Tolerance | WT/outer diameter |
| outer diameter ≤ 219.1 | ± 12.5% or ± 0.4mm | WT/outer diameter ≤ 2.5% | |
| 2.5% ＜ WT/outer diameter ≤ 5% | |||
| 5% ＜ WT/outer diameter ≤ 10% | |||
| WT/outer diameter > 10% | |||
| outer diameter > 219.1 | ± 20% | WT/outer diameter ≤ 2.5% | |
| ± 15% | 2.5% ＜ WT/outer diameter ≤ 5% | ||
| ± 12.5% | 5% ＜ WT/outer diameter ≤ 10% | ||
| ± 10% | WT/outer diameter > 10% |
15Mo3 pipes supplied by Chetan Steel are widely used in industries where high temperature and pressure resistance are essential. They are commonly applied in boilers, heat exchangers, pressure vessels, and steam pipelines. These pipes play a key role in power plants, petrochemical facilities, refineries, and oil and gas processing units. Their ability to handle thermal stress makes them ideal for hot water and steam transport systems. Additionally, 15Mo3 pipes are used in chemical processing equipment, ensuring reliable performance, safety, and long service life in demanding industrial operations.
