Chetan Steel stands out as a trusted manufacturer and supplier based in Delhi, specializing in high-quality Carbon Steel DIN 2609 Pipes designed for precision mechanical and structural applications. With state-of-the-art manufacturing facilities and rigorous quality control measures, the company ensures that its pipes meet DIN standards and cater to specific customer needs. Chetan Steel is committed to delivering consistent quality, precise dimensions, and reliable mechanical performance. Serving a variety of industries, including automotive, mechanical engineering, construction, power generation, and heavy machinery, the company is recognized for its competitive pricing, prompt delivery, and excellent technical support, making it a go-to source for DIN 2609 carbon steel pipe solutions.
Carbon Steel DIN 2609 Pipes are crafted from top-notch non-alloy carbon steel, featuring carefully controlled levels of carbon, manganese, and silicon. This specific chemical makeup grants the pipes impressive strength, ductility, and machinability. On the mechanical side, these pipes deliver moderate tensile and yield strength, dependable impact resistance, and stable performance under load. They also boast excellent dimensional accuracy and respond well to various forming and machining processes. The well-balanced mechanical properties of DIN 2609 pipes make them perfect for applications that demand structural reliability and consistent performance.
| Standard | AISI, DIN, EN, GB, IS, JIS, ASTM, ASME Pipe |
|---|---|
| DIN 2609 Grade St35-8 Seamless Pipe Size | 4 to 219mm W. T.: 0.5 to 20mm |
| Mild Steel DIN 2609 Grade St35-8 Welded Pipe Size | 5.0 mm – 1219.2 mm |
| DIN Gr. 2609 ST35-8 Steel EFW Pipe size | 5.0 mm – 1219.2 mm |
| Grade ST 35-8 DIN 2609 Pipe Swg & Bwg | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg. |
| Carbon Steel DIN 2609 Grade ST 35-8 Pipe Schedule | SCH5, SCH10, SCH10S, SCH20, SCH30, SCH40, SCH40S, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS |
| DIN 2609 Gr St35-8 Carbon Steel Seamless Pipe Size | 3.35 mm OD To 101.6 mm OD |
| Grade ST 35-8 DIN 2609 Welded Pipe Size | 6.35 mm OD To 152 mm OD |
| CS DIN 2609 Grade St35-8 Swg & Bwg | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg. |
| DIN2609 ST35-8 Steel Pipe wall thickness | 0.020″ –0.220″, (special wall thicknesses available) |
| DIN 2609 Gr St35-8 Length | Single Random, Double Random, Standard & Cut length Pipe & Tube |
| DIN 2609 Gr. St 35-8 Finish | Polished, AP (Annealed & Pickled), BA (Bright & Annealed), MF |
| Low Temperature Carbon Steel DIN 2609 Grade ST 35-8 Form | Round, Hydraulic, ‘U’ bent or Hollow,LSAW, Boiler, Straight Pipe, Clad Pipe, Rectangular, Square Pipe Etc |
| Mild Steel DIN 2609 Grade St35-8 Type | Welded, Seamless, ERW, EFW, Fabricated Pipe, ‘U’ bent or Hollow, Hydraulic, LSAW, Boiler, Straight Tube, Tube Coil, Round, Rectangular, Square Tube etc |
| ASME B36.19 DIN2609 Grade ST 35-8 End | Plain End, Beveled End, Treaded Pipe & Tube |
| DIN 2609 Grade St35-8 Marking | All DIN 2609 Grade ST 35-8 Carbon Steel Seamless Tubes are marked as follows: Standard, Grade, OD, Thickness, Length, Heat No. (Or according to the customer’s request.) |
| 2609 Gr. ST35-8 Application | Oil Pipe & Tube, Gas Pipe & Tube, Fluid Pipe & Tube, Boiler Pipe & Tube, Heat exchanger Tube |
| DIN Gr. 2609 ST35-8 Steel Value Added Service | Draw & Expansion as per required Size & Length, Polish (Electro & Commercial) Annealed & Pickled Bending, Machining Etc. |
| Mechanical Properties | |||||||||
| Yield Strength | Tensile Strength | Elongation A5 min | |||||||
|---|---|---|---|---|---|---|---|---|---|
| MPa min | ksi min | MPa min | MPa min | ksi min | Percentage | ||||
|  |  | 360 | 480 | – | 25 | ||||
| Outer diameter and wall Thickness | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| Execution | Size Range | OD Tolerance | Wall tolerance | ||||||
| Hot-rolled Pipe | OD – 80 mmOD > 80 mmWall < 12 mmWall – 12 mm | ± 0.4 mm± 0.5 % of OD | ± 0.7 mm± (5 % x wallthickness + 0.1 mm | ||||||
| Hot-rolled peeled Pipe | All sizesWall < 12 mmWall – 12 mm | + 0.25/- 0 mm | ± 0.8 mm± (5 % x wall thickness+ 0.2 mm) | ||||||
| Cold Worked Pipe cold-rolled or cold-drawn | OD < 40 mmOD 40 – 80 mmOD > 80 Wall Thickness< 6 mm Wall Thickness6 – 8 mm Wall Thickness > 8 | + 0.30/- 0 mm*+ 0.35/- 0 mm*+ 0.40/- 0 mm* | ± 0.30 mm± 0.35 mm± 0.40 mm | ||||||
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Chetan Steel is a trusted manufacturer and supplier of high-quality Carbon Steel DIN 2609 Pipe products in Delhi, India. Specializing in premium steel materials, we offer a wide range of products, including Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our diverse selection features Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Committed to reliable delivery and exceptional customer service, Chetan Steel ensures the supply of top-grade materials that deliver excellent performance across various industrial applications. Rely on Chetan Steel for all your Carbon Steel DIN 2609 Pipe needs.
| DIN | EN | BS | NFA | ASTM | ASME |
| DIN 2609 Grade St 37-0 | – | – | – | – | – |
Carbon Steel DIN 2609 Pipes find extensive use in applications that require solid mechanical strength and formability. They’re commonly utilized in the automotive and engineering sectors for creating structural components, frames, and mechanical parts. Additionally, these pipes play a vital role in machinery manufacturing, power transmission systems, and construction projects. In industrial fabrication, DIN 2609 pipes support load-bearing structures and various engineering applications. Their excellent machinability, durability, and cost-effectiveness make them a top choice for projects that demand reliable and efficient solutions.
Chetan Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Delhi, India.
